Zap 24 Pro
SKU: JRDSMZAP24P379€
– Zap 24 aluminium frame, Internal cable system
– Rigid PRO fork
– Aluminium stem and hanlebar
– Shimano Altus, 8 speeds
– Shimano MT200 160mm hidraulic disc brakes
– Cubiertas 24×2.30
AVAILABLE IN JUNE
Specifications
- FrameAluminium 6061, NEO Junior geometry, internal cable system, Oversize head-set , Forged dropout with post Mount brake system
- ForkAluminium PRO oversized
- SuspensionOversized aluminium one-piece
- ShiftersShimano Altus 1x8v
- Rear DerailleurShimano Altus
- Crankset32x152mm
- Bottom BracketSealed bearings
- CassetteShimano Altus 12-32t
- ChainKmc Z8
- WheelsIcon Meteor 24"
- Tires24x2.30
- Brake LeversShimano MT200
- BrakesShimano MT200, F-160 / R-160 Hydraulic disc
- HeadsetSemi-integrated
- HandlebarAluminium W: 600mm, L: 35mm, Ø: 31.8mm
- StemAluminium, Ø: 25.4mm
- SeatpostAluminium, Ø: 31.6mm
- SaddleSelle Royal
- PedalsIncluded
- EquipmentKickstand | Reflectors
- ColorsBlack (matt)
- NotesWe reserve the right to make changes to the product information (specifications, colors, equipment, etc.) at any time without prior notice. Bikes shown in the photos may not match the specification of the model or be equipped with mounting options other than those listed. Due to the screen some of the colors may suffer a slight variation with respect to the original model.
Geometry
| Talla | Altura del ciclista |
| Rueda de 12" (balance bike) | 86 - 102 cm |
| Rueda de 16" | 96 - 111 cm |
| Rueda de 20" | 114 - 132 cm |
| Rueda de 24" | 130 - 150 cm |
| Rueda de 27,5 (XS)" | 145 - 165 cm |
ZAP 24
| -- | |
| 1 | 310 |
| 2 | 524 |
| 3 | 115 |
| 4 | 405 |
| 5 | 290 |
| 6 | 20 |
| 7 | 1006 |
| 8 | 69° |
| 9 | 71,5° |
| 10 | 39 |
| 11 | 373 |
| 12 | 508 |
| 13 | 420 |
